ZAPCO 4 Ch. Class AB Amplifier with DSP

Description

• Features and Functions
  •4-Channel, Full Range, Class A/B
  •On-Board, Full Function, 8-ch. Digital Signal Processing
  •High-pass and low-pass filters, phase control, signal delay, and 15 channels of parametric equalization on each channel
  •Optical Digital Input
  •BT Streaming: Bluetooth Port for external APTX HD Module (optional)
  •Analog input gain controls
  Specifications
  •Power @ 4Ω: 4 x 25 watts
  •THD @ Rated Power < 0.5% THD
  •Power @ 2Ω: 4 x 35 watts
  •Power (Max): 4 x 70W
  •Signal to Noise Ratio > 90dB
  •THD + Noise < 0.2%
  •Channel Separation >60dB
  •Frequency Response 15Hz to 30KHz ±1dB
  •Dimensions in mm: 160(W) x 57(H) x 131(L) Overall: 160(W) x 57(H) x 156(L)
