ZAPCO Class D Mono Amplfier

Description

• Single channel, Class D,  Bass Amplifier

• Compact chassis

• Variable input gain control

• Variable electronic crossover

• Variable subsonic filter

• Variable bass boost control

• Variable center frequency for bass boost

• variable phase control

• Strappable to use a pair of amps on a single voice coil

• Dash mount remote gain control

• Power @ 1Ω: 1 x 1050 watts

• THD @ Rated Power  < 0.2%THD

• Power @ 2Ω: 1 x 750 watts

• Power @ 4Ω: 1 x 450 watts

• Signal to Noise Ratio > 100dB

• THD + Noise < 0.1%

• Efficiency > 85%

• Frequency Response 10Hz to 200Hz ±1dB

• Input Sensitivity .25v to 5v

• Dimensions in mm: 160(W) x 52(H) x 300(L) Overall: 160(W) x 52(H) x 325(L)
